ASTM D1200 Viscosity Flow Cup

  • 2.1mm – 5.8mm orifice diameter
  • 10 – 1200 cSt viscosity range
  • 30-100 sec flow times
  • Supplied with a certificate of conformity
  • Sheen 406/1, 406/2, 406/3, 406/4 & 406/5 equivalent


Viscosity Flow Cups

The Rhopoint Flow Cups are designed to accurately measure the viscosity of paints, inks, varnishes and similar products.

What is viscosity?

The term “viscosity” is a parameter that describes a fluids resistance to flow. This resistance is a measure of the friction and the forces of interaction between the layers of a fluid. This friction is apparent when one layer of fluid is made to move against another The greater the friction, the greater the amount of force required to cause the movement – known as “shear”.

The process of flow through an orifice can often be used as a relative measurement and classification of viscosity. This measured kinematic viscosity is generally expressed in seconds of flow time which can be converted into centistokes (cSt) using a viscosity calculator.

Flow cup cross section diagram

Manufactured from high grade aluminium alloy with stainless steel orifices (where indicated), the Rhopoint Flow Cups are available with a range of UKAS / ISO 17025 certified standard oils to confirm the flow cup is measuring within specification.

Paint pouring into a paint can - Flow cup measurement
Varnish being brushed onto wood - Flow cup measurement
Printing ink being tested for viscosity - Flow cup measurement


Instrument Information
MaterialHigh grade aluminium alloy, stainless steel orifice
Commodity Code9027 8091
Weight200 - 300g (depending on model)
ProductOrder codeOrifice diameterViscosity rangeFlow times
DIN flow cupASTM No.1 - 2.1mm (0.08”)RL-A-FC-ASTM12.1mm (0.08”)10 - 35cSt55s - 100s
DIN flow cupASTM No.2 - 2.8mm (0.11”)RL-A-FC-ASTM22.8mm (0.11”)25 - 120cSt40s - 100s
DIN flow cupASTM No.3 - 3.4mm (0.13”)RL-A-FC-ASTM33.4mm (0.13”)49 - 220cSt30s - 100s
DIN flow cupASTM No.4 - 4.1mm (0.16”)RL-A-FC-ASTM44.1mm (0.16”)70 - 370cSt30s - 100s
DIN flow cupASTM No.5 - 5.8mm (0.23”)RL-A-FC-ASTM55.8mm (0.23”)200 - 1200cSt30s - 100s
DIN flow cupThe orifices are manufactured from stainless steel.
